VanDOOR

Insights & guides

The VanDOOR technical blog

Articles sourced from official DoorLIFT DL-6 and VanDOOR AluLIFT manuals. Machinery Directive compliance, preventive maintenance, TCO, EU acoustic standards.

Pillar

Compliance hub

Machinery Directive 2006/42/EC compliance — Implications for bodybuilders

VanDOOR's editorial compliance hub. Directive text, machinery scope, responsibilities, PPE, EC declaration, FAQ.

June 1, 202618 min read

Latest articles

Field essentials

Two essentials to know before anything else

Critical procedures to stay operational — emergency release and installer qualification.

  • External release procedure: (1) insert the DoorLIFT key into the lock cylinder at the centre of the intermediate or top panel, outside face; (2) turn the key 90° clockwise and firmly pull the lock and cable out of the cylinder — the system disengages; (3) reinsert the cable and cylinder into the door lock housing, then operate the door by hand. On the AluLIFT, an internal release is available: pull the red sleeve marked 'EMERGENCY DOOR RELEASE' to disengage the motor lever from inside the box.

    SRCFR---Manuel-utilisateur-DL-6.mdl.617-632 + utilisation l.420-449

  • VanDOOR does not perform installation itself. AluLIFT integration must be carried out exclusively by qualified, trained bodybuilders or integrators, in accordance with Machinery Directive 2006/42/EC and best practice. The integrator guarantees regulatory compliance of the final assembly, verifies correct operation, commissions the system, and supplies the end user with the manual and CE Declaration of Conformity for the integrated equipment.

    SRCManuel-instruction-installation.mdl.45-72
